A36 Carbon Steel Bar
Prime Mill Grade | Certified China Exporter & Factory Direct Supply
A36 Carbon Steel Bar - Technical Overview & Specifications
A36 is a low-carbon steel containing trace amounts of manganese, phosphorus, sulfur, silicon and other elements such as copper. A36 has good weldability and high yield strength, and is the most specified structural steel plate by engineers. ASTM A36 is most commonly manufactured as a variety of structural steel parts. This grade is used for welded, bolted or riveted construction of bridges and buildings, as well as for general structural purposes. Due to its lowest yield point, A36 can be used to design lighter-weight structures and equipment, and provide good weldability.
Product Parameters
| Product Name | A36 Carbon Steel Bar |
| Standard | EN/DIN/JIS/ASTM/BS/ASME/AISI, etc. |
| Common Round Bar Specifications | 3.0-50.8 mm, Over 50.8-300mm |
| Flat Steel Common Specifications | 6.35x12.7mm, 6.35x25.4mm, 12.7x25.4mm |
| Hexagon Bar Common Specifications | AF5.8mm-17mm |
| Square Bar Common Specifications | AF2mm-14mm, AF6.35mm, 9.5mm, 12.7mm, 15.98mm, 19.0mm, 25.4mm |
| Length | 1-6meters, Size Accept Custom |
| Diameter(mm) | Hot Rolling Round Bar , 25-600 , Cold Rolling Square Bar , 6-50.8 |
| Hot Rolling Square Bar | 21-54 , Cold Rolling Hexagon Bar , 9.5-65 |
| Cold Rolling Round bar | 6-101.6 , Forged Rebar , 200-1000 |
| Surface Process | Bright, Polished, Black |
| Other Services | Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc. |
Chemical Composition
| C | Cu | Fe | Mn | P | Si | S |
|---|---|---|---|---|---|---|
| 0.25ο½0.290 | 0.20 | 98.0 | 1.03 | 0.040 | 0.280 | 0.050 |
Mechanical Properties
| A36 | Limit Tensile Strength | Tensile Strength, Yield Strength | Elongation at Break(Unit: 200mm) | Elongation at Break(Unit: 50mm) | Modulus of Elasticity | Bulk Modulus(Typical for Steel) | Poisson's Ratio | Shear Modulus |
|---|---|---|---|---|---|---|---|---|
| Metric | 400ο½550MPa | 250MPa | 20.0% | 23.0% | 200GPa | 140GPa | 0.260 | 79.3GPa |
| Imperial | 58000ο½79800psi | 36300psi | 20.0% | 23.0% | 29000ksi | 20300ksi | 0.260 | 11500ksi |
International Standard Grade Comparison
| National Standard GB | European Standard EN | American Standard ASTM | German Standard DIN,WNr | Japanese Standard JIS | French Standard AFNOR | British Standard BS | Canada HG |
|---|---|---|---|---|---|---|---|
| Q235B | S235JR | A283C | St37-2 | SM400A | E24-2 | 40A/40B | 230G |
| Italy UNI | India IS | Switzerland SS | Australia ONORM | Norway NS | Spain UNE | International Standards ISO | Portugal NP |
| Fe360B | IS2062 | 1311/1312 | RSt360B | NS12123 | AE235B-FN | E235B/Fe360B | FE360-B |
Product Features & Advantages
- Manufactured to EN/DIN/JIS/ASTM/BS/ASME/AISI, etc. with strict dimensional tolerance and surface quality
- Reliable Carbon Steel Bar solution for construction, machinery and industrial projects
- Custom processing available: cutting, bending, decoiling, slitting and surface polishing
- Mill Test Certificate (MTC) and full inspection provided
Applications & Industries
Customer Reviews & Mill Quality Audits
Overall Satisfaction from Global EPC & Steel Buyers
EN 10204 3.1 Chemical & Tensile Verification Passed
SGS, BV & Cotecna Third-Party Audits Supported
SEND INQUIRY FOR A36 Carbon Steel Bar
Please leave your specific requirements (size, grade, quantity, destination port). Our sales engineer will reply within 2 hours.
