Ductile Iron Pipe

Name: K10_Ductile_iron_pipe Ductile Iron Pipe
Brand: Ironex China
SKU: K10_Ductile_iron_pipe

Prime Mill Grade | Certified China Exporter & Factory Direct Supply

Click to Zoom

Origin: China (Mill Direct) China Steel Exporter EN 10204 3.1 MTC

Ductile Iron Pipe - Technical Overview & Specifications

Ductile Iron Pipe is a kind of pipe made of casting iron above No.18 by adding spheroidizing agent and then centrifugally casting into pipe by centrifugal ductile iron casting machine at high speed. Its full name is “ductile iron pressure pipe”, the main components include carbon, silicon, manganese, sulfur, phosphorus, magnesium and so on.

Product Parameters

Model Number	K8,K9,K7
Length	6m,8m,10m,etc.
Application	pipeline
Shape	ROUND
Hardness	≤230HB
Pipe Wall Thickness	6.0-64mm
Pull Strength	≥420MPa
Yield (≥MPa)	≥300Mpa
Material	Ductile Iron
Type	Casting
Processing Service	Welding,Bending,Punching,Decoiling,Cutting
Product Name	Ductile Iron Pipe
Standard	GB/T13295-2019,ISO2531/2003,EN545,EN598, ASTM,etc.
Shape	Round
Technique	Centrifugal casting
Material	K8,K9,K10,K12,DN80,DN100,etc.
Nominal Diameter	DN80-DN2600mm
Wall Thickness	6.0-64mm
Length	6m,8m,10m,etc.
Interface Type	T type,K type,N1 type,S type,etc.
Elongation	≥7%

Product Features & Advantages

Manufactured to GB/T13295-2019,ISO2531/2003,EN545,EN598, ASTM,etc. with strict dimensional tolerance and surface quality
Reliable Ductile Iron Pipe solution for construction, machinery and industrial projects
Custom processing available: cutting, bending, decoiling, slitting and surface polishing
Mill Test Certificate (MTC) and full inspection provided
